Item	Detailed Specification
Inside dimension	8050×3900×2650 mm (L×W×H)
Outside dimension	9550×4000×3150 mm (L×W×H)
Front door	Folding door, 4 folds, 3200×2600 mm (W×H),   without frame, aluminium alloy window frame, colour: Blue, with pressure   lock.
Emergency door	1 units, 800×2000mm (W×H), colour: white,   aluminium alloy window frame
Basement	Galvanized steel assemble, 300mm high,   underground, with adjustable bolts, quadrate steel support, full grilles made   by flat bar and twisted steel, galvanized.
Wall panel	Thickness: 50mm, width:1150mm, tongue and   groove structure, 0.476mm colour steel with 50mm thick rock wool inside,   colour: white.
Light	Ceiling Lights: 8Units×4Pcs=32Pcs×58W, side   Lights: 11Units×4Pcs=44Pcs×18W, with electronic ballasts, horizontally set,   lighting boxes are powered coated.
Generator cabinet	Inlet from back upper, outlet from back upper,   aluminium alloy steel frame; white coated steel outside, galvanized steel   inside, filled with heat preservation material in the middle.
Intake and Exhaust system	Inlet: 1×7.5KW turbo fan, power: 7.5KW, air   capacity: 25000m3/h.
	Outlet: 1×7.5KW turbo fan,   power: 7.5KW, air capacity: 25000m3/h.with damper
Heating system	RIELLO RG5S diesel burner, stainless steel heat   exchanger, pneumatic damper actuates from spraying to baking cycle. Max.   heating productivity: 260000kcal/h, maximum temperature: 80 degree
Purification system	Pre-filter, ceiling filter, fibreglass filter,   activated carbon filter
Roof	Galvanized steel
Water base paint system	On the both side of ceiling and middle with   water base paint system, stainless steel nozzle, with pressure extra fan.
Control system	Spraying, heat spraying, baking, time setting,   lighting switch, failure indicator, thermostat, power supply switch,   emergency stop, hour meter, temperature limit controller, pressure gauge,   pressure alarm system, All motors are normal start.
Total power	18.5KW (Power supply 3*380V, 50HZ)
